Konica Minolta accurio press 6136 professional printer

AccurioPress 6136

Top class productivity of up to 7,490 A4 pages per hour
Automatic density and registration adjustment
Multiple finishing options from cost-effective to professional
High speed colour scanner
Full OpenAPI and IWS support

Get in touch

Share

Interested to see all features and options and build your very own AccurioPress 6136?

Click here to configure your device

AccurioPress 6136series

Take your monochrome production to the next level with the AccurioPress 6136 series.

Features

AccurioPress 6136

In the fast-growing, digital high-volume print market, in-house printers and graphic communications providers have to focus on building up their business by producing a wider range of high-volume jobs more efficiently. For that, they need the best performance available in the market: The AccurioPress 6136 series comprises three models, the fastest of which provides a maximum speed of 7,490 A4 pages per hour. Latest technologies guarantee maximum uptime and outstanding black and white print quality. The superior product outline impresses with a comprehensive range of inline finishing options.

Professional finishing options
- Heavy-duty booklet making with Watkiss PowerSquare 224KR or Plockmatic SD350/500
- Own Konica Minolta options integrate inline or nearline via 3rd- party interface
World-leading imaging technologies
- Density balance and auto registration adjustment with optional humidifiying unit
- Open API/IWS support
- Simple paper catalogue settings
Outstanding media processing
- Paper weights from 40 to 350gsm, duplex up to 300gsm
- Envelope printing support via dedicated fusing unit
- For highly flexible print products

Productivity
- AccurioPress 6136/6136P: up to 7,490 A4 pages per hour
- AccurioPress 6120: up to 7,034 A4 pages per hour
Enhanced scanning performance
- Enhanced scanning performance
- Scanning and copying
- Supports dual-scan
- Multi-feeding detector
- Max. 240 ipm (A4, 300 dpi)
- Stock of paper: 300 sheets

Specifications & Downloads

Specifications

Printer specifications
System specifications
Scanner specifications
Copier specifications
Accessories

Print speed A4 AccurioPress 6136/P
136 ppm
AccurioPress 6120
120 ppm
Print speed A3 AccurioPress 6136/P
78 ppm
AccurioPress 6120
70 ppm
Print speed SRA3 AccurioPress 6136/P
74 ppm
AccurioPress 6120
66 ppm
Print speed / hour AccurioPress 6136/P
A4: 7,490 pph
A3: 4,526 pph
SRA3: 4,274 pph
AccurioPress 6120
A4: 7,034 pph
A3: 4,072 pph
SRA3: 3,846 pph
Print resolution 1,200 x 1,200 dpi

Paper weight 40-350 gsm
Duplex unit Non-stack type; 40-300 gsm
Paper sizes Min.: 95 x 139 mm
Max.: 324 x 483 mm (with PF-710)
Maximum image area 314 x 483 mm (with PF-710)
Maximum paper input capacity 18,000 sheets
Maximum paper output capacity 15,000 sheets (plus sub trays)
Main unit dimensions (W x D x H) 990 x 910 x 1,454 mm
Main unit weight 396 kg

Scan speed A4 Up to 240 ppm
Scan resolution 600 x 600 dpi
Scan modes TWAIN scan; Scan-to-HDD; Scan-to-FTP; Scan-to-SMB; Scan-to-eMail
Scan formats PDF; TIFF; secured PDF; XPS

Gradations 256 gradations
FCOT Less than 2.6 sec. (A4 LEF)
Magnification 25-400%, in 0,1% steps
Multiple copies 1-9,999

Integrated Color Care Unit IQ-501
Automatic colour adjustment
Automatic front to back registration
Real time colour adjustment on the fly
Real time registration adjustment on the fly
Hands free printer profiling
Colour Validation
Envelope fusing unit EF-105
Paper feed unit PF-709
PF-710
Heating unit HT-506
Folding and punching unit FD-503
Pre-printed sheet insertion (PI),
2 PI trays for 500 sheets each,
punching (2 and 4 hole),
folding (half-fold, z-fold, gate-fold,
letter fold in,
letter fold out,
double-parallel-fold),
sub tray for up to 200 sheets
Relay unit RU-518
RU-510
Sheet reverser; adapts processing speed to 125 ppm
Multi (GBC) punching unit GP-501
Multi punching of A4 sheets
User replaceable die sets for:
velo bind, plastic comb, wire bind, colour coil, pro click
Paper weight: 75 - 216 gsm

GBC Punch G2
Paper weights from 75 gsm to 300 gsm
Punches glossy and coated stocks from A5 to SRA3
Punches clear covers of up to 7 mil thickness
Supports tab punching
Offers die sets with the most popular professional binding styles
Double-punch capability for two-up sheet
Auto ring binder GP-502
Stacking, punching and binding of books, up to 102 sheets
self-adjusting bind elements (one size fits all);
paper weight: content 75-120 gsm; cover 163-216 gsm
Booklet making unit SD-506
Booklet making of up to 50 sheets (200 images),
saddle stitching,
trimming,
output tray for up to 50 booklets,
multi letter fold in (up to 5 sheets),
multi half fold (up to 5 sheets)

SD-513
Booklet making of up to 50 sheets (200 pages)
Saddle stitching with up to 4 staples with adjustable positions
Multi-letter fold-in (up to five sheets)
Multi-half-fold (up to five sheets)

Watkiss PowerSquare™ 224KR
Booklet making of up to 56 sheets
Saddle stitching with variable staple length
1-6 stitches evenly spaced on the spine of the book
Front-trimming; optional full bleed trimming available
Square folding
Offline usage possible

Plockmatic SD-500/SD-350
Booklet making of up to 200 pages on SD-500 (50 sheets)
Optional trim module for a smooth front-edge trim of the booklet
Optional square-fold module turns saddle-stitched booklets into professional flat square-folded books
Offline use also possible
Creasing unit CR-101
Creasing unit for SD-513
Slitting unit TU-503
Spine corner forming unit FD-504
Spine corner forming unit for SD-513
Stacking unit LS-506
Up to 5,000 sheets stacking capacity,
trolley mounted stacker,
auto-shift stacking,
sub tray for up to 200 sheets,
paper clamp mechanism
Perfect binding unit PB-503
Hot melt glue binding system
Integrated 1-side trimming of cover sheets
Books from A5 up to A4+ (307 x 221 mm)
Books from 10 sheets up to 30 mm spine width
Cover paper tray for up to 1,000 sheets
Sub tray for up to 200 sheets
Book stacking capacity of up to 3,300 sheets
2 stacks
Stapling unit FS-532
Stapling of up to 100 sheets; two-point and corner stapling; variable staple length (cutting mechanism); output for up to 4,200 sheets (A4); sub tray for up to 200 sheets; auto-shift sorting and grouping
Saddle stitching kit SD-510
Booklet making of up to 20 sheets (80 images)
Saddle stitching
cover sheets up to 300 gsm
output tray for booklets
multi-letter fold-in (up to 5 sheets)
multi-half-fold (up to 5 sheets)
Post inserter PI-502
Insertion of preprinted sheets; PI trays for 200 sheets each
Punch kit PK-522
Punching (2 and 4 holes selectable)
Humidifier unit HM-103
Post inserting unit PI-PFU
Mount Kit for 3rd party MK-737
Removable HDD kit RH-101
HD-511
Open Stacker OT-510
Output for up to 4,200 sheets (A4)
Sub tray for up to 300 sheets
Auto-shift sorting and grouping
Sub tray for up to 200 sheets

All specifications relating to paper capacity refer to A4-size paper of 80 gsm quality.
All specifications relating to scanning, copying or printing speeds refer to A4-size paper that is scanned, copied or printed crosswise in multipage, simplex mode.
The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
Some of the product illustrations contain optional accessories.
Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
Konica Minolta does not warrant that all specifications mentioned will be error-free.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
